| Cadre |
Aluminium : Prime 6061 Xtralite Full Butted Alloy, Forward Geometry, internal removable battery, tapered head tube, Boost 12×148 mm rear axle, integrated dropout speed sensor, Mondraker M068 Derailleur hanger |
| Fourche |
RockShox Recon Silver RL 29, 120 mm, Motion control, Solo Air, tapered steerer tube, Boost 15×110 mm axle, 42 mm offset. Réglages : compression adjustment at low-speed to lock, rebound, air preload |
| Moteur |
Bosch Performance Line CX Cruise GEN4, 25 km/h |
| Batterie |
Bosch PowerTube 625 Wh |
| Écran |
Bosch Purion |
| Manette de dérailleur |
Sram Trigger SX Eagle, X-Actuation 1:1, single click, 1×12-vitesses |
| Dérailleur arrière |
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, X-actuation 1:1, 12-vitesses |
| Cassette |
Sram PG-1210, 11-50 Dents |
| Chaîne |
Sram SX Eagle, Powerlock |
| Pédalier |
Race Face Aeffect ebike, 165 mm / Sram X-Sync 2 Eagle 34 Dents, steel, narrow-wide, 104 BCD |
| Freins |
Sram Level T, Hydr. Disc Brake, 2 piece caliper, Centerline 200/180 mm IS 6 bolts one-piece rotor |
| Roues |
MDK-HP1 27.5+, 35 mm internal width, tubeless ready, 32 spokes |
| Moyeux |
Avant : Formula DC711, Boost 15×110 mm, sealed bearings, IS 6 bolts / Arrière : Formula EHL148 Boost 12×148 mm, sealed bearings, IS 6 bolts |
| Pneus |
Maxxis Rekon+, tubeless ready, dual compound, EXO protection, 60 TPI, folding bead, 27.5×2.8″ |
| Guidon |
Onoff Sulfur 1.0 double butted 6061 alloy, 20 mm rise, 800 mm width, 9º backsweep, 5º upsweep, 31.8 mm barbore |
| Poignées |
Onoff Diamond, 1lock-on, 135 mm |
| Potence |
Onoff Sulfur FG 30 mm 0º, 6061 forged alloy, 31.8 mm barbore |
| Jeu de direction |
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, 41×30.2x7x45ºx45º (haut), 51.9x40x8x45ºx45º (bas) |
| Selle |
Fizik Terra Aidon X5, 145 mm |
| Tige de selle |
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, 31.6 mm diameter, 400 mm length |
| Poids |
— |
