| Cadre |
Aluminium : Haibike, FullNine Yamaha i630, Aluminium 6061, 120 mm travel |
| Fourche |
RockShox 35 Silver, Steel spring, 120 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, Boost 15 x 110 mm thru-axle |
| Amortisseur |
RockShox Monarch RL, Air, M8x25 |
| Moteur |
Yamaha PW-ST System, 250 Wh, 70 Nm, 25 km/h |
| Batterie |
Yamaha InTube, 630 Wh |
| Écran |
Yamaha Side Switch, 1.7″ LCD, 7 functions |
| Manette de dérailleur |
Sram SX Eagle, Trigger switch, 1×12-vitesses |
| Dérailleur arrière |
Sram SX Eagle, 12-vitesses |
| Cassette |
Sram Eagle PG-1210, 11-50 Dents |
| Chaîne |
Sram SX Eagle |
| Pédalier |
Haibike Components, The Crank +, Aluminium, 38 Dents |
| Freins |
Shimano MT420, Hydr. Disc Brake, 4-piston caliper, 203/180 mm Shimano RT30 rotors |
| Roues |
Rodi Tryp 30, With Eyelets, Double Wall, Aluminium |
| Moyeux |
Shimano MT400-B, Centerlock |
| Pneus |
Schwalbe Nobby Nic, Evo, SnakeSkin, 65-622, 29 x 2.6″ |
| Guidon |
Haibike Components, TheBar ++, 780 mm |
| Poignées |
Haibike MTB grips |
| Potence |
Haibike Components, TheStem ++, A-head, 31.8 mm, 7.0° |
| Jeu de direction |
Feimin, A-Head Alloy Tapered, Aluminium, Cartridge |
| Pédales |
Freeridepedal, Aluminium, with Reflector |
| Selle |
Selle Royal Vivo |
| Tige de selle |
Dropper-Post Remote 31.6, Aluminium, Telescope, 31.6 mm |
| Poids |
— |
| Poids maximum |
120 kg : le poids maximum du système comprend le vélo, le cycliste et la charge (porte-bagages ou remorque) |
| Coloris |
black/mango – matt&gloss |
